Průtok kapaliny s vysokou viskozitou

průtokoměry zařízení jsou určeny pro kapaliny s vysokou viskozitou, jako jsou mastné, lepidlo a asfalt. S ultra-širokým poměrem obratu až do 100:1 a ± 0,5% s vysokou přesností podporuje impuls, 4-20ma a rs485 výstupy pro přesné měření viskózní tekutiny.

Features of High Viscosity Liquid Flow Meter

Wide measuring range ratio 100:1, stable for high-viscosity media
High precision ±0.5% & excellent repeatability 0.1%
Wide temp range -196℃~200℃, pressure up to 45MPa
Multiple wetted materials: SS304, aluminum alloy, PP for corrosive fluid
Multi outputs: pulse, 4-20mA, RS485 Modbus RTU
Various connections: thread, flange, sanitary clamp, cutting sleeve
Compact positive displacement gear structure, low maintenance
Applicable for glue, fuel oil, asphalt, edible oil and hydraulic oil

Specification of High Viscosity Liquid Flow Meter

Basic Parameters	Power supply voltage	9-26VDC	Reverse power connection protection	Yes
	Ambient temperature	-20℃-70℃	Protection level	IP65
	Probe operating temperature	-20℃-80℃；-40℃-180℃(High Temperature Type)
Display Type Parameters	Electrical interface	M12*1 connector (with 2m cable)	Display	LCD backlight display
	Unit resolution	0.001	Accuracy	±0.5% read value
	No-load current	Current output type: 20mA	Repeatability	0.1%
	Accuracy	±0.5% of reading	Casing Material	Aluminum alloy
	Output type	Pulse (push-pull, three-wire); 4-20mA (two-, three-, four-wire); Dual-channel switch output (high/low flow alarm, relay); RS485 supports Modbus-RTU protocol
